Corner Transfer Machine
Multi-directional corner transfer for flexible line layout. Supports 90° and 180° turns to adapt to different factory layout requirements.
Features
- Supports 90, 180, 270 and 360 degree corner transfers
- Photoelectric sensor for PCB position detection
- Auto width adjustment with dual ball screw or SFU precision screw
- SMEMA interface for communication with other SMT equipment
- Multiple working modes: auto/manual switch
- PLC + touchscreen control system
Specifications
| PCB Size | 150×150mm ~ 340×270mm |
|---|
| Belt Width | 7mm, ESDanti-static belt |
|---|
| Transfer Height | 900 ± 20mm |
|---|
| PCB Conveying Speed | 9m/min |
|---|
| Travel Distance | 100mm |
|---|
| Auto Width Range | 150 ~ 300mm |
|---|
| Max Rotation Diameter | φ650mm |
|---|
| Voltage & Power | AC 220V ±10V, 50/60Hz, Approx. 400W |
|---|
| Dimensions | Approx. L700 × W700 × H1200mm |
|---|
| Weight | Approx. 180kg |
|---|
FAQ
- What is the PCB Size of the Corner Transfer Machine?
- 150×150mm ~ 340×270mm
- What is the Belt Width of the Corner Transfer Machine?
- 7mm, ESDanti-static belt
- What is the Transfer Height of the Corner Transfer Machine?
- 900 ± 20mm
- What is the PCB Conveying Speed of the Corner Transfer Machine?
- 9m/min
- How can I get a quotation for the Corner Transfer Machine?
- Contact Honred by email sales@honred.com or WhatsApp for a quotation and lead time.
- Do you ship the Corner Transfer Machine worldwide?
- Yes. Honred ships automation equipment worldwide with export packaging and installation support.
