Inline Automatic Screw Locking Machine (2 Batch)
Inline automatic screwdriver with 2-batch design for production line integration.
USD 20000.00
Features
- Work area divided into left and right sections
- Clamp and lift unit design
- Automatic track width adjustment
- Camera-assisted positioning
- Simultaneous screwing of two PCBs
- Supports series or parallel layout configuration
Specifications
| Air Pressure | 0.55±0.1 MPa |
|---|
| Axes | 6-axis |
|---|
| Dimensions | 1330×1450×1500mm |
|---|
| Power Supply | AC220V, 50HZ |
|---|
| Applicable Screws | M1.0-M2.0 |
|---|
| Weight | 350-420Kg |
|---|
| Feeding Method | Blow Feeding |
|---|
| Efficiency | 1.1-1.5s/2 screws |
|---|
FAQ
- What is the Air Pressure of the Inline Automatic Screw Locking Machine (2 Batch)?
- 0.55±0.1 MPa
- What is the Axes of the Inline Automatic Screw Locking Machine (2 Batch)?
- 6-axis
- What is the Dimensions of the Inline Automatic Screw Locking Machine (2 Batch)?
- 1330×1450×1500mm
- What is the Power Supply of the Inline Automatic Screw Locking Machine (2 Batch)?
- AC220V, 50HZ
- How can I get a quotation for the Inline Automatic Screw Locking Machine (2 Batch)?
- Contact Honred by email sales@honred.com or WhatsApp for a quotation and lead time.
- Do you ship the Inline Automatic Screw Locking Machine (2 Batch) worldwide?
- Yes. Honred ships automation equipment worldwide with export packaging and installation support.
