1. Functional features PLC control system, touch screen operation Function: With buffer storage PCB board and FIFO function Special air circuit design ensures that the PCB board is not easily damaged Automatic width adjustment, 14 track setting, 23 movable rails. Compatible with SMEMA interface 2. T
Features
Dual-layer connection belts at inlet with dust cover
Serial communication with inspection equipment (SPI/AOI)
Auto control with anomaly diagnosis, audio and visual alarm
Powered belts on each layer for active PCB transfer
NG buffer with OK pass-through, manual NG board retrieval
SMEMA compatible interface
Specifications
PCB Size
150×150mm ~ 340×270mm
PCB Thickness
0.5mm ~ 5.0mm
Transfer Height
900 ± 20mm
Direction
Left to Right
PCB Cycle Time
Approx. 6-10s/PCB
Belt Specification
width4mm, ESDanti-static belt
Buffer Capacity
Approx. 10-20 PCBs
Operating Mode
Loading/FIFO/LIFO/NG Buffer/OK Pass-through
Air Supply
0.6MPa, 6mmair tube, air consumption3L/min
Power Consumption
AC 220V ±10V, 50/60Hz, Approx. 1000W
Dimensions
Approx. L1200 × W1260 × H1650mm
Weight
Approx. 340kg
FAQ
What is the PCB Size of the NG Buffer Cache?
150×150mm ~ 340×270mm
What is the PCB Thickness of the NG Buffer Cache?
0.5mm ~ 5.0mm
What is the Transfer Height of the NG Buffer Cache?
900 ± 20mm
What is the Direction of the NG Buffer Cache?
Left to Right
How can I get a quotation for the NG Buffer Cache?
Contact Honred by email sales@honred.com or WhatsApp for a quotation and lead time.
Do you ship the NG Buffer Cache worldwide?
Yes. Honred ships automation equipment worldwide with export packaging and installation support.
