Dual-fixture, two-station design: while one fixture is fastening, the other fixture is used for assembly work
USD 22500.00
Features
Dual-fixture, two-station design: while one fixture is fastening, the other fixture is used for assembly work
A six-axis robot arm carries an external blow-and-pick fastening unit. The machine is equipped with one screw feeder using blow feeding and vacuum-pick fastening, which avoids the inefficiency of long-travel repeated screw pick-up
Handheld-controller programming and a long-reach robot arm, suitable for cabinets of various sizes
Specifications
Specification
Value
Screw type
M3 / M4 combination screws
Feeding method
Blow feeding from screw feeder
Positioning accuracy
±0.05 mm
Control method
Motion control card + handheld controller
Fastening rate
3 s per screw on average
Cabinet size (max.)
1000×1000 mm
FAQ
What is the Specification of the Robotic Arm Cabinet Screw Fastening Machine?
Value
What is the Screw type of the Robotic Arm Cabinet Screw Fastening Machine?
M3 / M4 combination screws
What is the Feeding method of the Robotic Arm Cabinet Screw Fastening Machine?
Blow feeding from screw feeder
What is the Positioning accuracy of the Robotic Arm Cabinet Screw Fastening Machine?
±0.05 mm
How can I get a quotation for the Robotic Arm Cabinet Screw Fastening Machine?
Contact Honred by email sales@honred.com or WhatsApp for a quotation and lead time.
Do you ship the Robotic Arm Cabinet Screw Fastening Machine worldwide?
Yes. Honred ships automation equipment worldwide with export packaging and installation support.
